Description
Specifications
| Â Specification |
- System Parameters
- Operating SystemAndroid 7.1
- ROM4 GB
- RAM2 GB
- CPUEmbedded Processor
- Display Parameters
- Screen Size10.1-inch
- Operation MethodTouch screen
- TypeColorful IPS
- Resolution1280 × 800
- Brightness410 cd/m2
- Video Parameters
- Supplement LightLow illumination, IR supplement lights
- Video StandardH.264
- Lens2
- FOVHorizontal: 88°, Vertical: 44°
-
WDR
Support
Â
- Resolution2 MP
- Audio Parameters
- Audio Compression StandardG.711 U, G.711 A
-
Audio Input
Built-in omnidirectional microphone
Â
- Audio OutputBuilt-in loudspeaker
- Audio Compression Bitrate64 Kbps
- Audio QualityNoise suppression and echo cancellation
- Volume AdjustmentAdjustable
- Capacity
- Fingerprint Capacity/
- User Capacity20000
- Card Capacity100000
- Face Capacity10000
- Linked Indoor Station Capacity500
- Event Capacity/
- Sub Door Station Capacity16
- Network Parameters
- Communication ProtocolTCP/IP, RTSP
- Wired Network10/100/1000 Mbps self-adaptive Ethernet
- Wi-Fi/
- Bluetooth/
- 3G/4G/
- Authentication
- Card Reading Frequency13.56 MHz
- Device Interfaces
- Alarm Input4 (2 exit butttons and 2 door contacts by default)
- Network Interface2 RJ45 (1 reserved)
- TAMPER1
- Exit Button2 (1 for lock control and 1 for DS-K2M060 relay control)
- RS-4852 (1 for Hikvision's card reader or elevator controller and 1 for DS-K2M060 by default)
- USB2 for internal use only
- Wiegand/
- TF Card1 (reserved)
- Alarm Output2 (reserved)
- Lock Control2 (1 relay and 1 RS-485 to control the DS-K2M060)
- Door Contact Input1
- Power Interface1
- General
- Button/
- InstallationSurface mounting & flush mounting
- Indicator0
- Weight1.265 kg
- Protective LevelIP65 & IK07
-
Working Temperature
-30° C to 60° C (-22° F to 140° F)
Â
-
Working Humidity
10% to 90%
Â
- Dimensions271 mm × 159.2 mm × 26.5 mm (10.7'' × 6.3'' ×1'')
- Battery/
- Power Supply12 VDC, 2 A
- Application EnvironmentOutdoor
- Power Consumption≤ 18 W
