Key Specifications
- Channels: Up to 128 IP Cameras.
- Input Bandwidth: 768 Mbps max (up to 576 Mbps in some configurations).
- Recording Resolution: Up to 12MP (4K), with support for various resolutions like 8MP, 6MP, 4MP, 1080p, etc..
- Video Output: 2x HDMI (4K), 1x VGA, supporting up to 4K resolution on HDMI.
- Storage: 24 SATA interfaces, supporting up to 10TB per HDD (up to 192TB total) for continuous recording, with HDD hot-swap and RAID support.
- Decoding: H.265+, H.265, H.264+, H.264, MPEG4, MJPEG.
- Decoding Capacity: e.g., 3-ch @ 12MP, 5-ch @ 8MP, 20-ch @ 1080p (30fps).
- Network Interfaces: 4x RJ45 10/100/1000M Ethernet.
- Audio: 1-ch RCA input, 1-ch RCA output, 2-way audio supported.
- Alarm I/O: 16/8.
- Chassis: 4U Rack Mountable.
- Power: Redundant power supply support (550W).
