Description
Specifications
| Software features | |
| Tag | 48 |
| Area | 32 |
| Zones | 96 (up to 48 PIRCAMs) |
| Installer | 4 |
| User | 46 |
| Admin | 1 |
| Voice Prompt | Supported |
| Loudspeaker built in | Supported |
| Memory Log stored | 5000 |
| Programming tools | Hik-Connect/Hik-Partner Pro/Web Portal/ IVMS4200/ Convergence Cloud |
| Firmware upgrade | APP/Web Portal |
| Arm modes | Away/Stay |
| Automatic Arm/Disarm Timers | Supported |
| Forced Arming with Open Zones | Supported |
| Diagnostics via the APP or Web | Supported |
| ARC protocol | SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK) Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685) Supports video verification and remote control |
| User APP for operating | Supported |
| Installer APP for programming | Supported |
| Web server for maintenance (offline configuration) | Supported |
| Hardware features | |
| RS232 output | Supported |
| SIM slot | Single |
| RF transmission | |
| RF Frequency | 433 Mhz |
| Wireless Security | Frequency Hoping 128 AES Encryption |
| GPRS on board | Supported |
| Electrical characteristics | |
| Power supply | Built in power supply |
| Battery type | Built in on board Battery Li |
| Battery life span | Up to 12 hours at normal temperature (The battery working time can be significantly reduced at low temperatures) |
| Wireless transmission | |
| Wired network | Supported |
| Wi-Fi Standard | Supported |
| Display | |
| LEDs Status | Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power |
| General | |
| Operation temperature | -10 °C to +55 °C |
| Shell material | Plastic |
| Dimension(WxHxD) | 170.0 mm (6.7") x 170.0 (6.7") mm x 38.6 mm (1.5") |
| Weight | 557.5 g(19.7 oz) |
| Color | White |
| Device management | |
| Keyfob | 32 |
| Wireless sounder | 4 (2 internal+2 External) |
| Keypad | 8 (Including Tag reader) |
| Wireless Repeater | 2 |
| Multi Transmitter | 4 |
| PIR Cam | Supported |
