Specifications
| Brand | Hikvision |
| Model | DS-PDD12-EG2 |
| Security grade | Grade 2 |
| Technology | Passive infrared and microwave |
| Detection range | 12 meters |
| Detection angle | 85,9º |
| Microwave frequency | 24 GHz (24,15 GHz to 24,25 GHz) |
| Microwave interval | Potentiometer adjustment |
| Installation height | From 1,8 to 2,4 meters |
| Installation | Wall or ceiling |
| Sensitivity | Automatic or adjustable (high or low) |
| Pet immunity | Available (Up to 10 kg) |
| Digital temperature compensation | Available |
| Tamper-resistant opening | Available (front) |
| Alarm output | Normally closed |
| LEDs indication | Alarm: blue PIR activated: green Microwave: orange |
| End-of-line resistors (EOL) | Available, selectable with jumpers |
| Alarm resistors | 1K, 2K2, 4K7, 5K6, 8K2 |
| Tamper resistors | 1K, 2K2, 4K7, 5K6 |
| Wired outputs | Alarm and tamper |
| Power | 9~16 VDC (consumption max. 17 mA) |
| Temp. operation | -10 ºC ~ +55 ºC |
| Operating humidity | 10% to 90 % |
| Application scenarios | Interior |
| Dimensions | 103,8 (H) x 65,7 (W) x 45,5 (D) mm |
