Specifications
| Brand | Hikvision |
| Model | DS-K1201AEF |
| Sensor | Optical CMOS fingerprint module |
| Capacity | 5.000 fingerprints |
| Activation sensor | Infrared auto-activation |
| Read time | < 1 sec |
| Card reading distance | 3 ~ 10 cm |
| Identification modes | Fingerprint and card (RFID EM 125 kHz) |
| Outputs | RS485, buzzer for status indication, tamper |
| Compatibility | Hikvision controllers DS-K2600T Series |
| Power | DC 12 V / 70 mA máx. |
| Degree of protection | Suitable for exterior IP65 |
| Temp. operation | -40 ºC ~ +70 ºC |
| Dimensions | 62 (W) x 132 (H) x 44 (D) mm |
| Weight | 200 g |
