| Specifications |
|---|
| Model | CS-DP2-R100-6E3WPFBS |
|---|
| General |
|---|
| Dimension | Screen and Base: 115.5 x 85.5 x 24.5 mm (4.55 x 3.37 x 0.96 inch) Camera: 71 x 71 x 48.3 mm (2.80 x 2.80 x 1.90 inch) |
|---|
| Weight | Product: 320 g (11.29 oz) With package: 595 g (20.99 oz) |
|---|
| Screen | 4.3 inch Color Touch Screen |
|---|
| Color | Silver |
|---|
| Button | Doorbell button, power button, screen wake-up button |
|---|
| Supported Peephole Diameter | 14 mm to 50 mm (0.55 inch to 1.97 inch) |
|---|
| Supported Door Thickness | 35 mm to 105 mm (1.38 inch to 4.13 inch) |
|---|
| Operating Conditions | -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
|---|
| Camera |
|---|
| Sensor | 1/2.7" Progressive Scan CMOS |
|---|
| Lens | 2.0mm @ F2.0 Viewing angle: 166° (Diagonal), 136° (Horizontal), 80° (Vertical) |
|---|
| Max. Resolution | 2K / 3MP |
|---|
| Day / Night Switch | ICR infrared filter |
|---|
| IR Night Vision Distance | Up to 16.4 ft / 5 m |
|---|
| Video & Audio |
|---|
| Video Frame Rate | 15 fps |
|---|
| WDR | DWDR |
|---|
| Audio Input | Built-in high sensitivity microphone |
|---|
| Audio Output | Built-in high-power speaker |
|---|
| Ringtones | Supports up to 5 ringtones, and the volume is adjustable |
|---|
| Function |
|---|
| Detection | Advanced PIR Motion Detection |
|---|
| PIR Angle | 110° |
|---|
| PIR Distance | Up to 20 ft / 6 m |
|---|
| PIR Sensitivity | Adjustable |
|---|
| Image Distortion Correction | Supports |
|---|
| Local Storage | Supports microSD card (Up to 512 GB) |
|---|
| Cloud Storage | Supports EZVIZ CloudPlay storage (Subscription required) |
|---|
| General Function | Cloud video encryption and image encryption |
|---|
| Network |
|---|
| Protocol | EZVIZ Cloud Proprietary Protocol |
|---|
| Video Intercom | Local and remote video intercom |
|---|
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
|---|
| Channel Bandwidth | Supports 20 MHz |
|---|
| Security | 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK, WPS |
|---|
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
|---|
| Power |
|---|
| Wiring | Hard-wired |
|---|
| Power Supply | DC 5V ± 10% |
|---|
| Power Consumption | Max. 2.2W |
|---|
