Description
Specifications
| Standard: | TCP/IP |
| Sensor: | 1/1.8 " Progressive Scan CMOS |
| Matrix size: | 8.3 Mpx |
| Resolution: | 3840 x 2160 - 8.3 Mpx, 4K UHD , 2560 x 1440 - 3.7 Mpx , 1920 x 1080 - 1080p 1280 x 960 - 1.3 Mpx 1280 x 720 - 720p |
| Scanning system: | Progressive |
| Lens: | 5.9 ... 147.5 mm |
| View angle: | 51 ° ... 2.6 ° (manufacturer data) 57 ° ... 3.2 ° (our tests result) |
| Optical zoom: | x 25 |
| Digital zoom: | x 16 |
| Range of IR illumination: | 200 m |
| Video output: |  |
| Preset rotation speed: | 240 °/s (horizontal) 200 °/s (vertical) |
| Rotation speed (manual control): | 0.1 °/s ... 160 °/s (horizontal) 0.1 °/s ... 120 °/s (vertical) |
| Horizontal rotation range: | 360 ° - continuous |
| Vertical rotation range: | -15 ° ... 90 ° |
| RS-485 interface: | |
| Number of presets: | 300 |
| Horizontal scan: |  |
| Route settings: | 4 |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Alarm inputs / outputs: | 2 / 1 |
| Audio: | External microphone input Audio output Audio detection Speaker built-in - Alarm siren Bi-directional audio streaming support Digital Noise Reduction |
| Main stream frame rate: | 25 fps @ 8.3 Mpx |
| Network interface: | 10/100 Base-T (RJ-45) |
| Network protocols: | IPv4/IPv6, HTTP, HTTPS, IEEE 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets |
| WEB Server: | Built-in |
| Max. number of on-line users: | 20 |
| ONVIF: | 19.12 |
| Memory card slot: | Micro SD memory cards up to 256GB support (possible local recording) |
| Mobile phones support: | Port no.: 8000 or access by a cloud (P2P) Android: Hik-Connect free application iOS: Hik-Connect free application |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Default IP address: | 192.168.1.64 |
| Web browser access ports: | 80 |
| PC client access ports: | Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application |
| Mobile client access ports: | 8000 |
| ONVIF port: | 80 |
| RTSP URL: | Main stream : rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/ Sub stream : rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/ |
| Main features: | WDR - 120 dB - Wide Dynamic Range 3D-DNR - Digital Noise Reduction EIS - Electronic Image Stabilization F-DNR (Defog) - Reduction of image noise caused by precipitation ROI - improve the quality of selected parts of image BLC/HLC - Back Light / High Light Compensation ICR - Movable InfraRed filter Parking action - this function enables to locate the camera to specific position automatically if operator doesn't operate the controller for some time ANR - Automatic Network Replenishment allows to save image to the card when the network connection with DVR is break (network failure) and next synchronize its NAS - Network Attached Storage support Privacy zones - max. 24 Motion Detection Sharpness - sharper image outlines The camera is equipped with a built-in heater with a thermostat Intelligent 3D Positioning System Intelligent Object Tracking Active deterrence function - Light and sound alarm Filtering of false alarms based on the recognition of persons and vehicles Intelligent Image Analysis : crossing the line (tripwire), intrusion, detection of entry into the area / exit from the area, abandoned/missing object, advanced face capture features - detection of up to 5 faces simultaneously |
| Power supply: | Hi-PoE, 24 V AC (power adapter included) |
| Power consumption: | ≤ 42 W |
| Housing: | Speed Dome, Metal |
| Color: | White |
| Operation temp: | -30 °C ... 65 °C |
| "Index of Protection": | IP66 |
| Vandal-proof: | IK10 |
| Weight: | 6.1 kg (with bracket) |
| Dimensions: | Ø 220 x 363 mm (without bracket) Ø 220 x 393 x 453 mm (with bracket) |
| Supported languages: | Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Finnish, French, Greek, Spanish, Dutch, German, Norwegian, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Vietnamese, Italian |
| Manufacturer / Brand: | Hikvision |
| SAP Code: | 327000245 |
