Description
Specifications
| Brand | HIKVISION |
| Range | PRO |
| Image sensor | 1/2.4" Progressive Scan CMOS |
| Maximum resolution | 6 Megapixel (3200x1800) |
| Main Stream rate | 25 fps (3200x1800, 2688x1520, 1920×1080, 1280×720) [%VAR%] |
| Extra Stream rate | 25 fps (1280x720, 640x480, 640×360) |
| Third stream rate | 10 fps (1920x1080, 1280×720, 640x480, 640×360) [%VAR%] |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Lens | Motorized varifocal 2.8~12 mm |
| Viewing Angle (FOV) | H: 106~35°, V: 56~20°, D: 127~41° |
| Range performance | 68~200 m (D), 27~79 m (O), 13~40 m (R), 7~20 m (I) |
| Electronic Shutter | 1/3~1/100.000 s |
| Minimum illumination | Low Light Powered by DarkFighter Colour: 0.003 Lux @(F1.4, AGC ON) 0 Lux with IR range 60 m |
| Day/Night | Removable mechanical ICR filter |
| Image improvements | WDR (120 dB), BLC, HLC, 3D-DNR, AWB, ROI Mirror function, Privacy masking |
| ANR | Yes |
| Alarms | 1 input / 1 output |
| Audio | 1 input / 1 output |
| Audio type | Mono |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio bit rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. * Motion detection 2.0, Facial recognition and AcuSense cannot be enabled at the same time. Enabling one function will disable the other 2 functions |
| Intelligent functions | AcuSense DeepLearning based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Inbound Region, Outbound Region, Outbound Region * Motion detection 2.0, Facial recognition and AcuSense cannot be enabled at the same time. Enabling one function will disable the other 2 functions |
| Facial recognition | Face Capture * Motion detection 2.0, Facial recognition and AcuSense cannot be enabled at the same time. Enabling one function will disable the other 2 functions |
| Internal memory | MicroSD card slot up to 512 GB |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 V / 1080 mA / 13 W max. / PoE+ IEEE802.3at |
| Degree of protection | Waterproof IP66, vandal-proof IK10 |
| Material | Metallic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | Ø 144.1 mm x 345.7 mm (D) |
| Base dimensions | Ø base 144.1 mm / Ø entre tornillos 96 mm / 4 tornillos |
| Weight | 1450 g |
