Description
Specifications
| Â
SIU-18：Single switch. |
|
SIU-68：With template SIU-60P (115×70×4.5mm) |
| SIU-88：With template SIU-80P (86×86×4.5mm) |
|
Features
|
|
■Activate without pressing to prevent any disease contagion. It is suitable for access control system that widely used in public areas such as hospitals or restaurants. It is also can be used as auto-control detection.
|
|
â– Specially designed to prevent any interference from other infra-red.
|
|
â– Built-in buzzer / tricolor ring LED light / orange indicator for user to control or connect to controller.
|
|
â– Standalone use or accommodate with other panel.
|
|
â– Waterproof stainless steel case.
|
Specification
| Â Voltage Input |
 12VDC~24VDC ±10% |
|
 Current Consumption |
 MAX. 55mA ±5% |
|
 State Indicator |
 Outer rim : Blue / Green /Red   Dynamic indicator :Orange |
|
 Buzzer |
 1 set (controllable) |
|
 Sensor Range |
 4~15 CM ±10% (Adjustment available) |
|
 Contact Output |
 N.O. / N.C. /COM. |
|
 Output Delay |
 Continuous output until the object is removed |
|
 Case |
 #304 Stainless Steel & PC Material |
|
 Contact load |
 0.5A@AC120V / 1A@DC24V |
|
 Machine Life |
 1000,000 times |
|
 Infrared Life |
 100,000 hours |
|
 Water resistant IP |
 IP 65 |
|
 Operation Temperature |
 0~75℃ |
