Description
Specifications
| Â
Specification: |
| • Strong and durable SUS304 stainless steel panel design which resists strong acid and alkali. |
| • SI-10 as mini infrared detector for access control push button auto-control detection. |
| • Suitable for hollow door frame and electrical box use. Voltage :DC12V~24V±10%. |
| • The diagram shows world universal use. |
| • The front of the detector is waterproof design with IP65 and above. |
| • Adjustable proximity range (3~12cm). Stable proximity range. |
| • Door opening time is able to set Trigger state (0.5~20sec) or Toggle mode output. |
| • Use of special signal design to avoid distraction of other external light. |
| • Operation temperature range: -10℃~70℃.Humidity 85%Rh max. |
|
• Contact rating: 1A@30VDC N.O./N.C. Output. |
|
• Dimensions: SI-85：86X86X26(mm) |
| • Weight: SI-85: 100g |
