Specifications
| Model | HDR-60-12 |
| Input Voltage Range | 85 to 264 VAC (Universal Input), 120 to 370 VDC |
| Output Voltage | 12 VDC (adjustable range 11V to 14V) |
| Output Current (Rated) | 5 A |
| Rated Power | 60 W |
| Efficiency (Typical) | Up to 86% at 230 VAC input |
| Mounting Type | DIN Rail TS-35/7.5 or TS-35/15 mountable |
| Dimensions (WxHxD) | 52.5 mm x 90 mm x 54.5 mm (3SU width) |
| Protection Features | Short circuit, overload, over voltage |
| Cooling Method | Free air convection (fanless design) |
| Operating Temp. | -30°C to +70°C (with derating) |
