Description
Specifications
Specifications
| Type of | angular |
| Mounting method | into the holes on the board |
| Operating voltage, V | 12 |
| Operating current, A | 0.05 |
| Size, mm | 6x6 |
| Height/length of push button (to contacts), mm | 8.35 |
| Pusher height/length, mm | 5.8 |
Specifications
| Type of | angular |
| Mounting method | into the holes on the board |
| Operating voltage, V | 12 |
| Operating current, A | 0.05 |
| Size, mm | 6x6 |
| Height/length of push button (to contacts), mm | 8.35 |
| Pusher height/length, mm | 5.8 |
