Description
Specifications
|
RJ45 Connector: |
|
|
Specification: |
|
|
Product Type: |
RJ45 Jack |
|
Length: |
16.85mm |
|
Number of Positions: |
8 |
|
Number of Contacts Loaded: |
8 |
|
Shielded: |
With |
|
Jack Configuration: |
1x 14 |
|
PCB Termination Type: |
Solder |
|
PCB Mount Angle: |
Side Entry |
|
Electrical Requirement: |
|
|
Rating Voltage: |
150V AC max |
|
Rating Current: |
1 Amp max. |
|
Contact Resistance: |
[30] Milliohms Max. (Initial), [50] Milliohms Max. (Final) |
|
Current leakage: |
1mA Max. [500]VAC for 1minute |
|
Dielectric withstanding Voltage: |
No creeping discharge or flashover shall occur |
