Description
Specifications
| Brand | HIKVISION |
| Range | Wi-Fi |
| Image sensor | 1/2.7" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2560x1440) |
| Main Stream rate | 25 fps (2560x1440, 1920×1080, 1280×720) |
| Extra Stream rate | 25 fps (640×360) |
| Compression | H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 101°, V: 55°, D: 119° |
| Electronic Shutter | 1/3~1/100.000 s |
| Minimum illumination | Colour: 0.005 Lux @(F1.6, AGC ON) 0 Lux with EXIR IR range 30 m |
| Day/Night | Removable mechanical ICR filter |
| Image improvements | BLC, HLC, 3D-DNR, AGC, AWB, Mirror function |
| ANR | Yes |
| Motion Detection | Yes |
| Internal memory | MicroSD card slot up to 256 GB |
| Network interface | Ethernet 10 / 100 BaseT Wi-Fi IEEE802.11 b/g/n |
| WiFi frequency | 2.412 GHz ~ 2.472 GHz |
| WiFi encryption mode | 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK |
| WiFi modulation | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 V / 600 mA / 7 W max. |
| Degree of protection | Weatherproof IP66 |
| Material | Cover : Polycarbonates Body: Polycarbonates |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | Ø 126 mm x 96.1 mm (H) |
| Base dimensions | Ø base 126 mm / Ø entre tornillos 83.6 mm / 3 tornillos |
| Weight | 590 g |
