Description
Specifications
System Parameters
| Specification | Details |
|---|---|
| Operating System | Embedded Linux Operating System |
| ROM | 32 MB |
| RAM | 256 MB |
| CPU | Embedded MCU Processor |
Display Parameters
| Specification | Details |
|---|---|
| Screen Size | N/A |
| Operation Method | N/A |
| Display Type | N/A |
| Resolution | N/A |
Video Parameters
| Specification | Details |
|---|---|
| Lens | 1 |
| Resolution | Main Stream: 1920 × 1080 Sub Stream: 720 × 480 |
| Field of View (FOV) | Horizontal: 129° Vertical: 75° |
| Wide Dynamic Range (WDR) | Supported |
| Supplement Light | Low-Illumination IR Supplement Mode Range: Up to 3 m |
| Video Compression Standard | H.264 |
Audio Parameters
| Specification | Details |
|---|---|
| Audio Compression Standard | G.711 U |
| Audio Input | Built-in Omnidirectional Microphone |
| Audio Output | Built-in Loudspeaker > 85 dB @ 20 cm |
| Audio Compression Bitrate | 64 Kbps |
| Audio Quality | Noise Suppression & Echo Cancellation |
| Volume Adjustment | Adjustable |
Capacity
| Specification | Details |
|---|---|
| User Capacity | N/A |
| Face Capacity | N/A |
| Card Capacity | N/A |
| Linked Indoor Station Capacity | 2 |
Network Parameters
| Specification | Details |
|---|---|
| Communication Protocols | TCP/IP, RTSP |
| Wired Network | 10 / 100 Mbps Self-Adaptive Ethernet |
| Wi-Fi Standard | N/A |
| Bluetooth Version | N/A |
| 3G / 4G Standard | N/A |
Device Interfaces
| Specification | Details |
|---|---|
| Alarm Input | 4 |
| Network Interface | 1 |
| Tamper | 1 |
| Exit Button | 2 |
| RS-485 | 1 |
| USB | N/A |
| Wiegand | N/A |
| TF Card | 0 |
| Alarm Output | N/A |
| Lock Control | 2 |
| Door Contact Input | 2 |
| Power Interface | 1 |
Performance
| Specification | Details |
|---|---|
| Multi-Factor Authentication | 2000 |
General
| Specification | Details |
|---|---|
| Buttons | 2 |
| Installation | Surface Mounting |
| Indicator | 3 |
| Weight | 385 g |
| Protection Level | IP65, IK08 |
| Working Temperature | -40 °C to +55 °C (-40 °F to 131 °F) |
| Working Humidity | 10% to 95% |
| Dimensions | 174 mm × 91 mm × 29 mm |
| Battery | N/A |
| Application Environment | Outdoor |
| Power Consumption | < 10 W |
| Languages | English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak |
