Specifications
| Brand | Hikvision |
| Product Series | KD8 Series Pro Modular Door Station |
| Model | DS-KD-KP |
| Type | Keypad Module |
| Material | Metal |
| Panel Type | Modular |
| Installation Method | Surface or Flush Mount |
| Operating Temperature | -40��C to 60��C (-40��F to 140��F) |
| Storage Temperature | -40��C to 70��C (-40��F to 158��F) |
| Operating Humidity | 10% to 90% RH |
| Dimensions | 98.5 mm x 100 mm x 33.7 mm |
| Power Supply | 12 VDC, 3W |
| Network Interface | 10/100Mbps Ethernet |
| Ingress Protection Rating | IP65 |
| Button Type | Physical Keys |
| Backlight | LED Backlit |
| Keypad Layout | 3x4 Numeric Keypad |
| Compliance | CE, FCC |
| Communication Protocol | TCP/IP |
| Operating Voltage | 12 VDC / 1 A |
| Warranty | 2 Years |
