Specifications
| Category | Details |
| Processor | Embedded MCU Processor |
| Physical Buttons | 6 Tactile pushbuttons |
| Interfaces | 1x Debug port, 8-digit DIP switch (for module addressing) |
| Durability | IP65 (Dust/Water) and IK07 (Impact resistance) |
| Power | 2W Max consumption (Powered via the main DS-KD8003-IME1 unit) |
| Mounting | Supports both Flush (recessed) and Surface (wall) mounting |
| Dimensions | 98.2 mm × 100.2 mm × 33.7 mm |
