Specifications
- Camera
- Image Sensor5 MP CMOS
- Max. Resolution2560 (H) ? 1944 (V)
- Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s - Day & NightColor
- Angle AdjustmentPan: 0? to 360?; Tilt: 0? to 75?; Rotate: 0? to 360?
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm fixed lens
- Focal Length & FOV2.8 mm, horizontal FOV: 99.7?, vertical FOV: 72?, diagonal FOV: 139.8?
- Lens MountM16
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 20m
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, Mirror, Smart Light, AGC
- Frame Rate
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080p@30fps, 1080p@25fps
CVI: 4MP@30fps, 4MP@25fps
AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps
CVBS: PAL/NTSC - Day/Night ModeColor
- Wide Dynamic Range (WDR)?130 dB
- Image EnhancementBLC, HLC
- White BalanceAuto/Manual
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- MaterialMain body: Metal, Enclosure: Plastic
- Dimension? 109.82 mm ? 85.56 mm (4.32" ? 3.37")
- WeightApprox. 350 g ( 0.77 lb.)
- Operating Condition-40? C to 60? C (-40? F to 140? F), Humidity 90% or less (no condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power
12 VDC ? 25%, Max. 3.5 W
*You are recommended to use one power adapter to supply the power for one camera. - Approval
- ProtectionIP67
