Specifications
| Output Voltage | -9 V |
| Output Current (Typical) | 1.5 A |
| Minimum Input Voltage | -11.5 V |
| Maximum Input Voltage | -35 V (absolute maximum) |
| Dropout Voltage (Typical) | 2 V at 1.5 A |
| Quiescent Current (Typical) | 5 mA |
| Operating Junction Temperature Range | 0 to 125 degrees Celsius |
| Internal Protection | Thermal overload, short circuit current limiting |
