Description
Specifications
| Brand | Hikvision |
| Range | VALUE |
| Inputs for IP cameras | Switch of 8 PoE IEEE802.3af/at ports [%VAR%] (max. 75 W) |
| Power over Ethernet | 8 (Max. 75W) |
| IP compatible cameras | HIKVISION (native protocol), ONVIF |
| Video outputs | 1xHDMI FullHD, 1xVGA simultaneous |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 |
| Display resolution | HDMI: 1920x1080, 1280x1024, 1280x720, 1024x768 VGA: 1920x1080, 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 60 Mbps downstream / 60 Mbps upstream |
| Stream Type | Video / Video + Audio |
| Main Stream recording | 4MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Decoding capacity | 2CH@4MPx, 4CH@1080p |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Motion Detection | Motion detection 2.0 with classification of humans and vehicles applied in motion detection Only available using cameras that also have Motion Detection 2.0. |
| Alarms | Does not have |
| Recording method | Manual, programmed, motion detection |
| External Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Remote connections | 16 |
| Internal memory | 1 SATA HDD 3.5" of up to 6 TB (not included) |
| Communication | 2 x USB 2.0 (Rear part) / 1 x RJ45 10/100M (Ethernet) |
| Power | DC 48 V / 1.8 A, ≤ 10 W (without HDD) |
| Operating temperature | -10ºC ~ 55ºC (10%-90% Humidity) |
| Dimensions / Weight | 48 (H) x 265 (W) x 225 (D) mm / 1 Kg (without HDD) |
