Description
Specifications
| Category | Specification | Details |
|---|
| Overview | Lead Time | Usually in Stock |
| Main | Product or Component Type | Uninterruptible Power Supply (UPS) |
| Range of Product | Easy UPS |
| UPS Type | Line Interactive |
| Run Time for Load | 360 W (Min–Max: 36–360 W) |
| Max Capacity Used | 100% |
| Rated Power | 360 W |
| Rated Power (VA) | 700 VA |
| Maximum Configurable Power | 700 VA / 360 W |
| Transfer Time | 6 ms typical, 10 ms maximum |
| Wave Type | Stepped approximation to a sinewave |
| Input | Main Input Voltage | 230 V AC (1 phase) |
| Input Connection Type | IEC 60320 C14 |
| Input Voltage Limits | 170–280 V AC |
| Network Frequency | 50/60 Hz ±5% (auto-sensing) |
| Power Factor (Cos φ) | 0.51 |
| Output | Output Voltage | 230 V AC (1 phase) |
| Output Frequency | 50/60 Hz ±1 Hz (sync to mains) |
| Output Connection Type | 2 × Universal Receptacle |
| Runtime | Full Load Runtime | 00:00:01 @ 360 W |
| Half Load Runtime | 00:06:00 @ 180 W |
| Maximum Runtime | 120 minutes |
| Battery | Battery Type | Lead-acid (internal, included) |
| Battery Voltage | 12 V |
| Battery Capacity | 7.0 Ah |
| Battery Recharge Time | 8 hours |
| Battery Life | 2–3 years |
| Replacement Battery | APCRBC110 |
| Extended Runtime | No |
| Interface & Control | Control Panel | LED status display (on-line / on battery) |
| USB Compatible | No |
| Protection | Surge Energy Rating | 273 J |
| Physical | Colour | Black |
| Cable Length | 1.2 m |
| Number of Cables | 1 |
| Height | 138 mm |
| Width | 98 mm |
| Depth | 310 mm |
| Net Weight | 4.2 kg |
| Mounting Support | Floor |
| Mounting Mode | Desktop installation, not rack-mountable |
| Environment | Product Certifications | CE, CB |
| Standards | EN/IEC 62040-1 & 62040-2 |
| Operating Temperature | 0–40 °C |
| Storage Temperature | -15–40 °C |
| Operating Humidity | 0–95% (non-condensing) |
| Storage Humidity | 0–95% (non-condensing) |
| IP Protection | IP20 |
| Acoustic Level | 40 dBA |
| Operating Altitude | 0–3000 m |
| Storage Altitude | 0–3000 m |
| Packing Units | Package Type | PCE |
| Units per Package | 1 |
| Package Dimensions | 22.2 × 34.6 × 14.2 cm |
| Package Weight | 4.5 kg |
| SCC14 | 10731304417610 |
| Warranty | Warranty Period | 24 months |
