| Camera |
| Transducer |
1/2.8" Progressive Scan CMOS |
| Broadcast Standard |
IP |
| Resolution max. |
8Mpx @3840 × 2160 |
| Sensitivity |
0.005 Lux (color, AGC ON), 0 Lux at IR |
| Shutter speed |
1/3 s to 1/100,000 s |
| Slow shutter mode |
supported |
| Auto-Iris |
N/A |
| Focus |
N/A |
| Lens |
2.8 mm |
| Recording angle (horizontal) |
Horizontal FOV 107° |
| Head adjustment range |
Pan: 0° to 355°, Tilt: 0° to 75° |
| IR Illuminator |
| IR Range |
up to 40m |
| Wavelength IR |
850 nm |
| Image compression |
| Video compression |
- Main stream: H.265+/ H.265/H.264+/H.264
- Auxiliary streams: H.265/H.264/ MJPEG(for stream 3)
|
| H.264 |
Base Profile/ Main Profile/ High Profile |
| H.264+ |
Main stream |
| H.265 |
Main profile |
| H.265+ |
Main stream |
| Bitrate video |
from 32 Kbps to 8 Mbps |
| Smart Features |
| ROI |
1 permanent region |
| Picture |
| Main stream - max. number of frames |
20 fps @ 8Mpx |
| Image Features |
BLC, 3D-DNR, True-WDR, HLC, ACUSENSE |
| AcuSense Smart Functions |
Motion Detection 2.0 - classification of objects, facial detection, perimetric protection |
| Image Settings |
Saturation, exposure, contrast, sharpness, AGC, white balance |
| Day/Night Mode |
automatic/manual switching |
| Network |
| Network interface |
1x RJ45 Ethernet 10/100 Mbps self-adaptive |
| Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, Open Network Video Interface (S Profile, G Profile) |
| Selected functions |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
| Simultaneous preview |
up to 6 channels |
| Calling an alarm |
Motion detection (including AcuSense functions), video sabotage, exception |
| Link |
Upload to FTP/microSD/NAS card, surveillance center notification, recording launch |
| Number of users/hosts |
- up to 32 users
- 3 levels of permissions: Administrator, Operator, User
|
| Client software |
iVMS-4200 (lite), Hik-Connect, iVMS-5200 |
| Supported browsers WEB |
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
| General |
| Power supply |
- 12 VDC
- PoE (802.3af, class 3)
|
| Power consumption |
- 12 VDC, 0.6A, Max: 8.5W
PoE: (802.3af, 36V to 57V), 0.3A to 0.2A, Max: 10W
|
| MicroSD slot |
up to 256Gb |
| Material |
Plastic + Aluminium |
| Tightness class |
IP67 |
| Operating Temp. / Permissible humidity |
- -30 °C to 50 °C
- <95% (non-condensing)
|
| Dimensions |
Ø 74.4 mm × 179.2 mm |
| Weight |
585g |
