Description
Specifications
| Specification | Details |
|---|
| Shell | Metal material |
| Net Weight | 2.92 kg (6.44 lb) |
| Gross Weight | 4.12 kg (9.08 lb) |
| Dimensions (W × H × D) | 440 mm × 44 mm × 220.8 mm (17.3'' × 1.7'' × 8.7'') |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100-240 VAC, 50/60 Hz, Max. 4 A |
| Max. Power Consumption | 250 W |
| Power Consumption in Idle | 25 W |
| Installation Mode | Rack (equipped with mounting ears) |
| Surge Protection | 6 KV |
| Ports | 24 × Gigabit PoE, 2 × Gigabit fiber optical |
| MAC Address Table | 8 K |
| Switching Capacity | 52 Gbps |
| Packet Forwarding Rate | 38.69 Mpps |
| Internal Cache | 4.1 Mbits |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Power Pin | End-span: 1/2(+), 3/6(-) |
| PoE Port | Ports 1 to 24 |
| Max. Port Power | 30 W |
| PoE Power Budget | 225 W |
