Description
Specifications
General
| Specification | Details |
|---|---|
| Shell | Metal Material |
| Net Weight | 2.50 kg (5.51 lb) |
| Gross Weight | 3.57 kg (7.87 lb) |
| Dimensions (W × H × D) | 440 mm × 44 mm × 220.8 mm (17.3" × 1.7" × 8.7") |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (No Condensation) |
| Relative Humidity | 5% to 95% (No Condensation) |
| Power Supply | 100–240 VAC, 50/60 Hz, Max. 2.5 A |
| Max. Power Consumption | 150 W |
| Power Consumption (Idle) | 25 W |
| Installation Mode | Rack Mount (Mounting Ears Included) |
| Surge Protection | 6 KV |
Network Parameters
| Specification | Details |
|---|---|
| Ports | 16 × Gigabit PoE Ports 2 × Gigabit Fiber Optical Ports |
| MAC Address Table | 8K |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 26.79 Mpps |
| Internal Cache | 4.1 Mbits |
PoE Power Supply
| Specification | Details |
|---|---|
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| PoE Power Pin | End-Span: 1/2 (+), 3/6 (–) |
| PoE Ports | Ports 1–16 |
| Max. Port Power | 30 W |
| PoE Power Budget | 125 W |
