Specifications
| Brand | Hikvision |
| Model | DS-PDCL12DT-EG2 |
| Security grade | Grade 2 |
| Technology | Passive infrared and microwave |
| Microwave frequency | 24 GHz |
| Detection range | 12 meters |
| Detection angle | 360º |
| Detection zones | 172 |
| Installation height | From 2,4 to 4 meters |
| Installation | Ceiling |
| Sensitivity | Automatic, Low |
| Pet immunity | Not available |
| Digital temperature compensation | Available |
| Tamper-resistant opening | Available (front) |
| Alarm output | Normally closed |
| LEDs indication | Alarm: blue PIR activated: green Microwave: red |
| End-of-line resistors (EOL) | Available, selectable with jumpers |
| Alarm resistors | 1K, 2K2, 4K7, 5K6, 8K2 |
| Tamper resistors | 1K, 2K2, 4K7, 5K6 |
| Wired outputs | Alarm and tamper |
| Power | 9~16 VDC (consumption max. 100 mA) |
| Temp. operation | -10 ºC ~ +55 ºC |
| Operating humidity | 10% to 90 % |
| Application scenarios | Interior |
| Dimensions | 120 (Ø) × 33.2 (D) mm |
