Description
Specifications
Camera
| Specification | Details |
|---|---|
| Image Sensor | 2 MP CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Min. Illumination | 0.0005 Lux @ F1.0, AGC ON 0 Lux with White Light ON |
| Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
| Day & Night | 24/7 Color Imaging |
| Angle Adjustment | Pan: 0° to 360° Tilt: 0° to 90° Rotation: 0° to 360° |
| Signal System | PAL / NTSC |
| Slow Shutter | Max. 16× |
| Light Alarm | Solid Light Alarm (White Light) |
Lens
| Specification | Details |
|---|---|
| Lens Type | Fixed Focal Lens |
| Focal Length & FOV | 2.8 mm: Horizontal FOV 106°, Vertical FOV 56°, Diagonal FOV 129° 3.6 mm: Horizontal FOV 83°, Vertical FOV 44°, Diagonal FOV 100° |
| Lens Mount | M12 |
Illuminator
| Specification | Details |
|---|---|
| Supplement Light Type | White Light |
| Supplement Light Range | Up to 20 m |
| Smart Supplement Light | Yes |
| Specification | Details |
|---|---|
| Image Parameters Switch | STD / HIGH-SAT / HIGHLIGHT |
| Image Settings | Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, AGC |
| Frame Rate | TVI: 1080p @ 25/30 fps CVI: 1080p @ 25/30 fps AHD: 1080p @ 25/30 fps CVBS: PAL / NTSC |
| Day/Night Mode | Color |
| Wide Dynamic Range (WDR) | ≥ 130 dB |
| Image Enhancement | WDR, BLC, HLC, Global, HLS |
| Privacy Mask | 4 Programmable Privacy Masks |
| Noise Reduction | 3D DNR / 2D DNR |
| White Balance | Auto / Manual |
Interface
| Specification | Details |
|---|---|
| Video Output | Switchable TVI / AHD / CVI / CVBS |
Event
| Specification | Details |
|---|---|
| Motion Detection | 4 Programmable Motion Areas |
General
| Specification | Details |
|---|---|
| Material | Metal |
| Dimensions | 161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76") |
| Weight | Approx. 388 g (0.86 lb) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F), Humidity ≤ 90% (Non-Condensing) |
| Communication | HIKVISION-C |
| Language | English |
| Power | 12 VDC ± 25%, Max. 2.9 W Recommended: one power adapter per camera |
