Specifications
| Category | Specification | Details |
| Model | Amplifier Chip | STMicroelectronics TDA7266 |
| Power | Supply Voltage ($V_{CC}$) | DC 3V – 18V (12V Recommended) |
| Output Power | 7W + 7W (Dual Channel / Stereo) | |
| Peak Output Current | 2A (Internally limited) | |
| Audio | Speaker Compatibility | 4 – 8 $\Omega$ impedance; 5W – 15W rating |
| Total Harmonic Distortion | 0.05% (at 1W output) | |
| Fixed Gain | 26 dB | |
| Protection | Safety Features | Short-circuit & Thermal Overload Protection |
| Physical | Dimensions | 45 x 33 x 30 mm |
| Connectivity | 5.08mm Terminal Blocks & DC Jack |
