Specifications
Operation system |
Linux |
Display Size |
2.4-inch |
Resolution |
320 × 240 |
Type |
LCD-TFT display screen |
Audio output |
1 loudspeaker, 1 buzzer |
Wired network |
TCP/IP, 10/100Mbps, self-adaptive |
Wi-Fi |
Support |
Card capacity |
3000 |
Fingerprint capacity |
3000 |
Event capacity |
100,000 |
Card type |
Mifare 1 card |
Card reading distance |
0 to 4.5 cm |
Fingerprint module |
Optical fingerprint module |
Power supply |
12 VDC/1 A |
Working temperature |
-10 °C to +55 °C |
Dimensions |
205 mm × 76.5 mm × 37 mm (8.07" × 3.01" × 1.46") |
Installation |
Surface mounting |
