Description
Specifications
Rated current: 25A.
Rated operational voltage: Ue=690 V AC
Rated operational power: 22kW, AC-23A, 440V AC
Switching: Switch with padlocking device to prevent unauthorized personnel switched ON.
Locking: Max 3 Padlocks.
Solid or rigid strand wire: 2.5 sq.mm to 10 sq.mm
Fine-strand wire with sleeve: 0.75 sq.mm to 6 sq.mm
Terminal tightening torque: 1.7 Nm
Material of enclosure: PP (polypropylene)
Cable Entry: With elastic membranes, which can be removed for cable entry via cable glands, sealing range 9.0-21.0 mm
Lid: Lid fasteners sealable without accessories.
Included: Retaining strap and external brackets for wall fixing included.
