Description
Specifications
Rated current: 20A.
Rated operational voltage: Ue=690 V AC
Rated operational power: 15kW, AC-23A, 440V AC
Switching: Switch with padlocking device to prevent unauthorized personnel switched ON.
Locking: Max 3 Padlocks.
Solid or rigid strand wire: 1.0 sq.mm to 1.5 sq.mm
Fine-strand wire with sleeve: 0.5 sq.mm to 4 sq.mm
Terminal tightening torque: 0.8Nm
Material of enclosure: PP (polypropylene)
Cable Entry: With elastic membranes, which can be removed for cable entry via cable glands, sealing range 9.0-21.0 mm
Lid: Lid fasteners sealable without accessories.
Included: Retaining strap and external brackets for wall fixing included.
