Features
* Built-in recording function and SD interface
* With auto setting ID function, easy for operation
* Adopt digital equalization module and noise reduction processing module for audio processing, to ensure clear and good sound quality. With 1 channel audio input and 1 channel audio output.
* Smart touch buttons, easy operation. With recording, playback control, mode, quantity switching and volume shortcut key.
* With 4 meeting modes: FIFO; NORMAL; FREE; APPLY.
* Spokesman quantity limitation: option for 1, 2, 4, 6. Chairman is not restricted.
* Support Max 30 pieces microphone units.
* Hand in hand cable connection way, easy for installation and maintain.
* With 1 group original audio channel output to connect amplifier.
* With 1 group original audio channel output to connect external recording device.
* Support 24V DC power supply.
* Control unit enclosure and circuit both has the connection with ground line, to ensure the function of antistatic 6000V.
* Delicate desktop design.
* With 3.5mm headphone jack.
* Adopt 8 core aviation plug.
Specifications
|
Model |
TS-0605M |
|
Microphone quantity |
≤30 |
|
Channel |
1CH |
|
Frequency Response |
30 ~ 20KHz |
|
SNR |
>75 dB(A) |
|
Dynamic Range |
>80 dB |
|
Crosstalk |
>80 dB |
|
THD |
<0.05% |
|
Power Supply |
>24V DC |
|
Audio Input |
LINE IN : 350mV Balance |
|
Audio Output |
LINE OUT 1: 1V Balance |
|
Output Load |
>1KΩ |
|
Static Consumption |
10W |
|
Output Consumption |
70W |
|
Connector |
8 core aviation plug |
|
Working Temperature |
-10℃<~+60℃ |
|
Working Humidity |
20%～80% relative humidity, without condensation |
|
Dimension |
210 x 132 x 50mm |
|
Weight |
1.65kg |
