Description
Specifications
Specifications
- Output Voltage: 24VDC @ 1A
- LAN Activity Indicator: No
- Gigabit LAN Port: Yes
- Remote Reset Capability: Yes
- Reset Button: Yes
- Input Voltage: 90-260VAC @ 47-63 Hz
- Input Current: 0.3A @ 120VAC, 0.2A @ 240VAC
- Inrush Current: <30A Peak @120VAC, <60A Peak @ 230VAC
- Efficiency: 75+%
- Efficiency: 75+%
- Output Ripple: 1% Max.
- Switching Frequency: 50 kHz
- Line Regulation: ± 1%
- Load Regulation: ± 3%
- 2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
- Operating Temperature: 0 to 40° C
- Storage Temperature: -30 to 70°C
- Operating Humidity: 35 to 95% Non-Condensing
- AC Connector: IEC-320 C6
- Data IN / POE: RJ45 Shielded Socket
- Surge Protection: Difference and Common Mode
- Clamping Protection: 11V Data, 60V Power
- Max. Surge: 1500A (8/20µS) Power
- Peak Pulse Current: 36A (10/1000µS) Data
- Response Time: <1 nS
- Dimensions: 87 x 84 x 29.2 mm
- Weight: 99.4 g
