Description
Specifications
| Category | Specification | Details |
|---|
| Overview | Lead Time | Usually in Stock |
| Main | Product Type | Uninterruptible Power Supply (UPS) |
| Range of Product | Easy UPS |
| UPS Type | Line Interactive |
| Run Time for Load | 600 W (Min–Max: 60–600 W) |
| Max Capacity Used | 100% |
| Rated Power | 600 W |
| Rated Power (VA) | 1000 VA |
| Maximum Configurable Power | 1000 VA / 600 W |
| Transfer Time | 6 ms typical, 10 ms maximum |
| Wave Type | Stepped approximation to a sinewave |
| Input | Main Input Voltage | 230 V AC (1 phase) |
| Input Voltage Limits | 170–280 V |
| Input Connection Type | NEMA 5-15P |
| Network Frequency | 50/60 Hz ±5% (auto-sensing) |
| Output | Output Voltage | 230 V AC (1 phase) |
| Output Frequency | 50/60 Hz ±1 Hz (unsynchronised) |
| Output Connection Type | 4 × Universal Receptacle |
| Battery | Battery Type | Lead-acid (internal, included) |
| Battery Voltage | 12 V |
| Battery Capacity | 9.0 Ah |
| Battery Recharge Time | 8 hours |
| Battery Life | 3–5 years |
| Extended Runtime | No |
| Interface & Control | Control Panel | LED status display (on-line / on battery) |
| Alarm | On battery, low battery, overload (continuous tone) |
| USB Compatible | No |
| Protection | Surge Energy Rating | 156 J |
| Physical | Colour | Black |
| Cable Length | 1.20 m |
| Number of Cables | 1 |
| Height | 92.5 mm |
| Width | 160.5 mm |
| Depth | 305 mm |
| Net Weight | 5.7 kg |
| Mounting Preference | No preference |
| Mounting Mode | Not rack-mountable, Wall mount compact |
| Environment | Product Certifications | CE |
| Standards | EN/IEC 62040-1 & 62040-2 |
| Operating Temperature | 0–40 °C |
| Storage Temperature | -20–50 °C |
| Operating Humidity | 0–90% |
| Storage Humidity | 0–90% |
| IP Protection | IP20 |
| Acoustic Level | 40 dBA |
| Operating Altitude | 0–6667 ft |
| Storage Altitude | 0–15,240 m |
| Packing Units | Package Type | PCE |
| Units per Package | 1 |
| Package Dimensions | 23.7 × 37.3 × 14.3 cm |
| Package Weight | 6 kg |
| SCC14 | 10731304338250 |
| Warranty | Warranty Period | 24 months |
