Specifications
| System Parameters | |
|---|---|
| Storage: | cards information: 100,000 (200,000 expandable) access control events : 300,000 (600,000 expandable) |
| Capacity: | 16M |
| Processor: | 32-bit |
| Device Interfaces | |
| Output Interface: | Door Switch Relay×4, Alarm Relay×4 |
| Uplink Communication Interface: | TCP/IP Network Interface and RS-485 Interface |
| Input Interface: | Alarm Input×4, Door Magnetic×4, Door Switch×4, Case Input×8, Tamper-proof ×1 |
| Downlink Communication Interface: | RS-485 and Wiegand (w26/w34) |
| Accessible Card Reader: | 8 Card Readers (RS485 Interface) and 4 Card Readers (Wiegand Interface) Connectable |
| General | |
| Working Voltage: | DC 12V/1A |
| Power Dissipation (with Load): | ≤100W |
| LED Indicator: | Power Supply Status, Communication Status, Working Status |
| Certification: | CE, FCC |
| Working Humidity: | 10% to 90% (Non-Condensing) |
| Working Temperature : | -20°C to +65°C (-4°F to +149°F) |
| Dimensions (L×W×H): | 370x345x90mm (14.6x13.6x3.5") |
