Description
Specifications
Network parameters
- Interface number: Eight 10/100 Mbps Interfaces
- Interface type: RJ-45, Full/Half-Duplex, MDI/MDI-X Self-Adaptive
- Standard: IEEE802.3, IEEE802.3u, IEEE802.3x
- Processing type: Storing and Forwarding
- Flow control: IEEE802.3x (Full-Duplex), Back Pressure (Half-Duplex)
- Priority queue: Four
- Max. VLAN: 64
- VLAN ID No.: VID1 to VID4094
- MAC address list: 8K
- Internal buffer: 1 Mbit
General
- Power supply: 24 VDC
- Power consumption: ≤8 W
- Working temperature: -10°C to 55°C (14°F to 131°F)
- Working humidity: 10% to 90%, No Condensation
- Dimensions (L × W × H): 176 mm × 91 mm × 32 mm (69.3" × 35.8" × 12.6")
*Notes
- Interfaces (A1, A2, A3, A4, A5, and A6) are 6 adaptive 10/100 Mbps LAN interfaces supporting network cable powering.
- Interfaces (A7 and A8) are 2 adaptive 10/100 Mbps cascading LAN interfaces
