DESCRIPTION
Triac 600V 25A TG25C60
G Series Information
- 16~70 Amps
- 400~600 Volts
- TO-238AB
The TG series are isolated moled Triacs suitable for a wide range of applications like copiers, Microwave ovens, solid state switches, motor control, light control, and heater control.
Specifications
| Â Item Number:Â Â | TG25C60 |
| Vdrm (volts):Â | 600 Volts |
| Vrrm (volts):Â | 600 Volts |
| Idrm Peak (mA):Â | 5 MilliAmps |
| Irrm Peak (mA): | 5 MilliAmps |
| It (rms) Amps:Â | 25 Amps |
| Itsm Amps:Â | 250 Amps |
| I2T@60Hz (A2Sec):Â | 260 |
| Vtm (volts):Â | 1.4 Volts |
| dv/dt (V/microseconds): | 50 |
| di/dt (A/microseconds):Â | 50 |
| tq (microseconds):Â | 10 MicroSeconds |
| Igt (mA): | 50 MilliAmps |
| Vgt (volts):Â | 3 Volts |
| Junction Temp.:Â | 257 Degrees F |
| Mounting Force:Â | 8 |
| RoHS Compliant:Â | Yes |
| Picture No.:Â | SEMJ_TRIAC_TG-C-E-F |
| H x W x D:Â | .89 in x 1.54 in x .91 in |
| Â Net Weight: | .95 OZ |
| Â Gross Weight: | .95 OZ |
