| Camera |
|---|
| Image Sensor | 1/4" Progressive Scan CMOS | 1/2.9" Progressive Scan CMOS |
|---|
| Shutter Speed | Self-adaptive shutter | Self-adaptive shutter |
|---|
| Lens | 2.8mm, view angle:92° (Horizontal), 110°(Diagonal) | 2.8mm, view angle:106° (Horizontal), 130°(Diagonal) |
|---|
| Lens Mount | M12 | M12 |
|---|
| Day & Night | IR-cut filter with auto-switching | IR-cut filter with auto-switching |
|---|
| DNR | 3D DNR | 3D DNR |
|---|
| Image |
|---|
| Max. Resolution | 1280 x 720 | 1920 x 1080 |
|---|
| Frame Rate | Max. 25fps; Self-adaptive during network transmission | Max. 20fps; Self-adaptive during network transmission |
|---|
| Compression |
|---|
| Video Compression | H.264 | H.264 |
|---|
| H.264 Type | Main profile | Main profile |
|---|
| Video Bit Rate | HD; Standard. Adaptive bit rate | Full HD; HD; Standard. Adaptive bit rate |
|---|
| Auto Bit Rate | Self-adaptive | Self-adaptive |
|---|
| Max. Bitrate | 2Mbps | 2Mbps |
|---|
| Network |
|---|
| Smart Alarm | Motion detection | Motion detection |
|---|
| Wi-Fi Pairing | AP pairing | AP pairing |
|---|
| Protocol | EZVIZ cloud proprietary protocol | EZVIZ cloud proprietary protocol |
|---|
| Interface Protocol | EZVIZ cloud proprietary protocol | EZVIZ cloud proprietary protocol |
|---|
| General Features | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark | Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark |
|---|
| Interface |
|---|
| Storage | Support Micro SD card (Max. 256G) | Support Micro SD card (Max. 256G) |
|---|
| Power | Micro USB | Micro USB |
|---|
| Wi-Fi |
|---|
| Standard | IEEE802.11b, 802.11g, 802.11n | IEEE802.11b, 802.11g, 802.11n |
|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz | 2.4 GHz ~ 2.4835 GHz |
|---|
| Channel Bandwidth | Supports 20MHz | Supports 20MHz |
|---|
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
|---|
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps | 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
|---|
