Description
Specifications
Camera
| Specification | Details |
|---|---|
| Image Sensor | 2 MP CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Min. Illumination | 0.005 Lux @ F1.2, AGC ON 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: -30° to 30° Tilt: 0° to 80° Rotate: -180° to 180° |
| Signal System | PAL / NTSC |
| Slow Shutter | Max. 16× |
Lens
| Specification | Details |
|---|---|
| Lens Type | Fixed Focal Lens |
| Focal Length & FOV | 2.8 mm: Horizontal FOV 94.5° 3.6 mm: Horizontal FOV 79.1° 6 mm: Horizontal FOV 50° |
| Lens Mount | M12 |
Illuminator
| Specification | Details |
|---|---|
| Supplement Light Type | IR |
| Supplement Light Range | Up to 20 m |
| Smart Supplement Light | Yes |
| Specification | Details |
|---|---|
| Image Settings | Brightness, Sharpness, Mirror, AGC |
| Frame Rate | PAL: 1080p @ 25 fps NTSC: 1080p @ 30 fps |
| Day/Night Mode | Auto / Color / BW (Black & White) |
| Wide Dynamic Range (WDR) | ≥ 120 dB |
| Image Enhancement | WDR, BLC |
| Privacy Mask | 4 Programmable Privacy Masks |
| Noise Reduction | 3D DNR |
| White Balance | Auto / Manual |
Interface
| Specification | Details |
|---|---|
| Video Output | 1 × CVBS Output (75Ω / BNC) |
| Audio Output | 1 × RCA Audio Out |
| Built-in Microphone | Yes |
Event
| Specification | Details |
|---|---|
| Motion Detection | 4 Programmable Motion Areas |
General
| Specification | Details |
|---|---|
| Power | 12 VDC ± 30%, Max. 5 W |
| Material | Main Body: Metal Enclosure: Plastic |
| Dimensions | 97 mm × 99.5 mm × 46.6 mm (3.82" × 3.92" × 1.83") |
| Weight | Approx. 300 g (0.66 lb) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F) Humidity ≤ 90% (Non-Condensing) |
| Language | English |
