Specifications
Specifications
Input voltage: AC110/220V
Output voltage: DC0-12V 35A
Rated power: 480W
Product size: 21.5CM (long) *11.5CM (wide) *5CM (high)
Input voltage & frequency range -110/220VAC/47 ~ 63Hz
Weight: 9.6 oz
Start impact current -20A@120VAC (cold start)
The output range of - + 100% (rated output voltage)
Overload protection -105% ~ 200% (rated load), self recovery
Overvoltage protection -115% ~ 135% (rated output voltage)
 Short circuit protection - self recovery
Output start time - 2S@120VAC 1.0S@230VAC
Output hold time - more than 10mS@120VAC, more than 20mS@230VAC
 The insulation strength - input - output: AC1500V, 1min
Input - Case: AC1500V, 1min Output - Case: DC500V, 1min
The working environment of C - 10 to 50 DEG C; 20% ~ 90%RH (no condensation)
EMC standard - EN55022 Class B reference design; EN61000-4-2/-3/-4/-5/-6/-11
