Specifications
| Category | Specification |
|---|
| Product Name | Current Transformer |
| Model | RCT-60 |
| Brand | ANDELI |
| Primary Current Rating | 400 A |
| Secondary Current Rating | 5 A |
| Accuracy Class | 0.5 |
| Frequency | 50/60 Hz |
| Rated Burden | Typically ≤ 5 VA (product dependent) |
| Core Type | Toroidal / laminated core |
| Insulation Level | Standard class for CT applications (IEC / ANSI) |
| Accuracy Limit Factor | Standard for Class 0.5 |
| Turns Ratio | 400:5 |
| Phase Angle Error | Low phase error (Class 0.5) |
| Mounting Style | Window / through-hole type |
| Output Terminals | Screw / terminal block |
| Operating Temperature | −5 °C to +40 °C (typical) |
| Application | Metering & protection in electrical panels & switchboards |
