Specifications
| rated insulation voltage | Ui = 690 V a.c. / 1000 V d.c. |
| impact strength | IK 08 (5 Joule) |
| static load | mounting plate or DIN rail = 6.5 kg lid = 1.6 kg |
| power dissipation capability at Δϑ = 40 K | Pde = 53 watts |
| wall thickness | enclosure = 3 mm lid = 3 mm |
| material | PC (Polycarbonate) |
| degree of protection | IP 66 |
| mounting width | 275 mm |
| mounting height | 275 mm |
| max. installation depth | 146 with built-in mounting plate mm |
| max. installation depth | 135 with built-in DIN rail mm |
| width | 300 mm |
| height | 300 mm |
| depth | 170 mm |
| weight | 2,08 kg |
| in accordance with | IEC 62208:2011 |
