Specifications
| Attribute | Value |
| Brand | KEMET |
| Capacitance | 47 nF |
| Voltage | 630 V dc |
| Tolerance | ±5 % |
| Series | R76 |
| Lead Pitch | 15 mm |
| Length | 18 mm |
| Depth | 7.5 mm |
| Height | 13.5 mm |
| Dimensions | 18 x 7.5 x 13.5 mm |
| Lead Diameter | 0.8 mm |
| Maximum Operating Temperature | +105 °C |
| Dielectric Material Family | Polypropylene (PP) |
| Minimum Operating Temperature | -55 °C |
| Dissipation Factor | 0.0003 % @ 1 kHz, 0.0004 % @ 10 kHz, 0.0015 % @ 100 kHz |
| Terminal Type | Radial |
| Lead Length | 30 mm |
