Description
Specifications
Video/Audio input
- Video compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Analog video input 8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- HDTVI input 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 Note: The 3 MP signal input is only available for channel 1 of DS-7104HQHI-K1, channel 1/2 of DS-7108HQHI-K1, and channel 1/2/3/4 of DS-7116HQHI-K1.
- AHD input 4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI input 4 MP, 1080p25, 1080p30, 720p25, 720p30
- CVBS input Support
- IP video input 4-ch (up to 12-ch) Up to 6 MP resolution Supports H.265+/H.265/H.264+/H.264 IP cameras
- Audio compression G.711u
- Audio input/Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio output
- HDMI/VGA output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Encoding resolution When 1080p Lite mode not enabled: 4 MP lite/3 MP/1080p/720p/WD1/4CIF/VGA/CIF; When 1080p Lite mode enabled: 4 MP lite/3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF
- Frame rate Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video bit rate 32 Kbps to 6 Mbps
- Audio output 1-ch, RCA (Linear, 1 KΩ)
- Audio bit rate 64 Kbps
- Dual stream Support
- Stream type Video, Video & Audio
- Synchronous playback 8-ch
Network management
- Incoming bandwidth 48 Mbps
- Remote connections 64
- Network protocols TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
- SATA 1 SATA interface
- Capacity Up to 6 TB capacity for each disk
External interface
- Network interface 1, RJ45 10M/100M self-adaptive Ethernet interface
- USB interface Real panel: 2 × USB 2.0
- Power supply 12 VDC
- Consumption (without HDD) ≤ 12 W
General
- Working temperature -10 °C to +55 °C (+14 °F to +131 °F)
- Working humidity 10% to 90%
- Dimensions (W × D × H) 200 × 200 × 45 mm (20.06cm(7.9) x 20.06cm(7.9) x 4.57cm(1.8) inch)
- Weight (without HDD) ≤ 1 kg (2.2 lb)
