Specifications
System parameters
- Processor: High-Performance Embedded SOC Processor
- Operation system: Embedded Linux Operation System
Camera parameters
- Image sensor: CMOS 2MP HD Colorful Camera
- Light sensitivity: Low Illumination- Lens: f1.96 mm, F 2.2
- Field of view: 180º(Horizontal), 96º(Vertical)
Video parameters
- Video compression standard: H.264
- Video streaming: Dual Stream, Main Stream: 1080P, Sub-Stream: VGA
- Anti-flicker frequency: 50 Hz, 60 Hz
- Wide dynamic range: WDR
Audio parameters
- Audio streaming: Two-Way, Full Duplex
- Audio input: Built-in Omnidirectional Microphone
- Audio output: Built-in Loudspeaker
- Audio compression standard: G.711 U
- Audio compression rate: 64 Kbps
- Audio quality: Noise Suppression and Echo Cancellation
Light supplement
- Light supplement mode: IR Supplement, IR Distance: 5 Meters
- Wavelength: 940 nm
Network parameters
- Network protocol: TCP/IP, RTSP
- Network interface: 1 Wireless Interface (Wireless Network Card), Supporting 2.4 GHz
Event
- Motion Detection: Supported
Alarm
- Motion Detection Alarm: Supported
Device interfaces
- TF card: Max. 128 G
- Button: 1 Call Button, 1 Reset Button
General
- Ingress protection level: IP 54
- Power supply: 16 VAC to 24 VAC
- Power frequency: 50 Hz to 60 Hz- Power consumption: Max. 0.6 A
- Working temperature: -30° C to +50° C (-22° F to 122° F)
- Working humidity: 10% to 90%
- Dimensions: 122.4 mm x 45.9 mm x 28.1 mm (4.82" x 1.81" x 1.11")
