Specifications
Key Technical Specifications (AM72-A/Series)
- Dimensions:
72×7272 cross 7272×72 mm - Accuracy: 1.5 Class (some models 0.5–2.5)
- Display: 3 1/2 digit LED display (often red or green)
- Input Types: AC Ammeter, AC Voltmeter, DC Ammeter, DC Voltmeter
- AC Current Range: Direct up to
100A100 A100A, higher with 1A/5A External CT - DC Current Range:
25μA25 mu A25𝜇A to
50A50 A50A, higher with External Shunt - Voltage Range: Up to
600V600 V600V (direct), higher with External Resistor - Frequency: 45-65 Hz
- Operating Temperature:
-10∘Cnegative 10 raised to the composed with power C−10∘C to
50∘C50 raised to the composed with power C50∘C - Auxiliary Power: Commonly 220V AC or
110V AC±10%110 V AC plus or minus 10 %110V AC±10% - Protection Class: IP41 (Front), IP20 (Body)
