Specifications
Key Technical Specifications:
- Model: AM96-KW
- Dimensions:
96×96mm96 cross 96 mm96×96mm (front panel). - Display: 3 1/2 or 4 digits, red LED display.
- Measurement Range (Voltage):
0−600V0 minus 600 V0−600V AC. - Measurement Range (Current):
0−9999A0 minus 9999 A0−9999A (uses Current Transformer, typically 5A input). - Frequency:
50/60Hz50 / 60 Hz50/60Hz. - Accuracy: Class 0.5 or 1.5.
- Auxiliary Power: AC 110V or 220V
±10%plus or minus 10 %±10%. - Input Method: Direct connection or through Current Transformers (CT) / Potential Transformers (PT).
- Operating Temperature:
-10∘Cnegative 10 raised to the composed with power C−10∘C to
50∘C50 raised to the composed with power C50∘C.
