Specifications
Key Specifications & Features
- Model: AM96-V (Andeli or similar series)
- Display: 3 1/2 digit or 4-digit LED, typically red or green.
- Mounting Size: 96mm x 96mm (cutout ~91x91mm).
- Input Type: AC or DC Voltage (dependent on specific model configuration).
- Measuring Range: Commonly 0-600V (AC/DC); for voltages
>600Vis greater than 600 cap V>600𝑉, a potential transformer (PT) is required. - Accuracy: Class 0.5% or 1.0% (
±1plus or minus 1±1 or
±2plus or minus 2±2 digits). - Auxiliary Power: 110V AC or 220V AC (
±10%plus or minus 10 %±10%). - Operating Conditions: -20°C to 55°C, humidity
<85%is less than 85 %<85% RH. - Refresh Rate: Typically 2-3 readings per second.
