MZQ100A600V Fast recovery diode rectifier bridge MZQ 10 20 30 50 75 100 150 Amp 600V FRD For UPS SMPS
reminder
1. About product selection
The marked current of the power module is the average value of the on state, not the actual effective value of long-term operation. When selecting, sufficient margin should be left based on the actual working environment and conditions.
(1) Pure resistive load 2-2.5 times margin: actual current (A) × 2 (~2.5)=Module nominal current (A) (2) Inductive load 6-7 Signal margin: Actual current (A) × 6 (~7)=Module nominal current (A)
2. Radiator configuration
When the actual working current of the device is greater than 5A, please be sure to configure a suitable heat sink for use
