Description
Specifications
Operation speed:0.01mm`50m/swc
Operatiom frequency:Mechanical :120 operation/min electrical:30 operation min
Insulation resistance:1000MΩ (below 500VDC) 1000MΩmin (below500VDC)
Contact resistance:25MΩ Min (inital)
Dielectric strength:1000VAC 50/60HZ for 1 minutes betweeen non-continous terminal 2000VAC 50/60HZ for
1 minute between current-carrying and nin-cureent-carrying parts and between each terminal and ground
Vibration:Mechenical durability:1.000m/s2(approx 100G's)
Mechenical durability:1.000m/s2(approx 100G's)
Mechenical durability:300m/s2(approx 30G/s)
Ambient operaing temperature:-10ºC~+70ºC
Humidity:<95%RH
Service life: Mechanically:20.000.000 operation min
Electrucally:500.000 operations min
Degree protection:IEC IP65
