Description
Specifications
| Model number | LXW5 |
| Contact material | Copper; Silver |
| Contact form | 1NO+1NC |
| Action method | Reset |
| Rated voltage (Ue) | 380VAC, 220VDC |
| Rated thermal current (Ith) | 10A |
| Contact resistance | 30mΩ max (initial value) |
| Insulation resistance | 100MΩ min at 500Vdc |
| Dielectric strength | 1000Vac, 50/60 Hz for 1 min between terminals of the same polarity 2000Vac, 50/60 Hz for 1 min between current-carrying metal part and ground 2000Vac, 50/60 Hz for 1 min between each terminal and non-current-carrying metal part |
| Machine life | 20x106 operations min |
| Electrical Life | 5x105 operations min |
| IP Rating | IP62 |
| Operating temperature | -25-80 ℃ |
| Operating humidity | 35 to 85% RH, no condensation |
| Alias name | LXW5 series limit switch |
